MOTION 92 MINIMAL CASEMENT SYSTEM
Motion 92 has been meticulously engineered to address the demands of more conservative architectural contexts, where performance and refinement are equally essential. The system accommodates glass thicknesses from 32 to 57 mm, making it an ideal solution for projects requiring high-performance triple glazing.
Beyond the classic tilt-and-turn configuration, Motion 92 supports a full range of opening typologies, including hinged, projecting, tilting, and French double-leaf designs. All typologies are available for both inward- and outward-opening sashes, offering exceptional design flexibility without compromising the system’s visual consistency.
The series also extends seamlessly into door applications, featuring bespoke multi-point locking systems crafted from stainless steel for enhanced security and durability.
With its advanced glazing capacity and precision engineering, Motion 92 is the ideal choice for projects demanding maximum thermal efficiency and superior acoustic insulation—delivering comfort, elegance, and lasting performance.
Technical characteristics
| Frame Profile Height | 45/52 mm |
| Frame Profile Width | 86 mm |
| Sash Profile Height | 65 mm |
| Sash Profile Width | 72 mm |
| External Frame-Sash visible face impression | 62 mm |
| Internal Frame-Sash visible face impression | 71.5 mm |
| External T-Joint-Sash visible face impression | 74.5 mm |
| Internal T-Joint-Sash visible face impression | 75 mm |
| Opening Type | Hinged, Tilt and Turn, Outward |
| Max sash width | 1600 mm |
| Max sash height | 2500 mm |
| Max Sash weight | 150 Kg |
| Glazing width possibilities | 32-57 mm |
| Max Locking Points | 9 |
| Thermal Break width | 30 / 35 |
| Sealing Type | 3 Gasket layers |
Performances
| Fabrication Thermal Transmittance | ≥0.9 W/(m2K) |
