MOTION 61 FS MINIMAL FOLDING SYSTEM, THERMAL SYSTEM
MOTION 61 FS is not just a door—it is a portal to a new dimension of space, light, and elegance. Crafted for the most discerning residences and visionary commercial projects, it transforms interiors into fluid, luminous environments, blurring the line between inside and out.
With a sash face width of only 27mm and a combined mullion of 68mm, MOTION 61 FS holds the distinction of being the slimmest folding door in the world. Its minimal profile allows light, air, and vision to flow freely, giving every space a sense of boundless openness and refined sophistication.
Every detail has been meticulously considered. Panels glide effortlessly on a state-of-the-art top suspension system, while precision-engineered stainless-steel rollers ensure whisper-quiet movement for years of flawless operation. With panels soaring up to 3 meters high, the system offers a grand scale without compromise, preserving both beauty and structural integrity.
The Infinity Floor and flush thresholds create a seamless connection to the outdoors, while concealed side frames and ultra-slim central mullions maintain an aesthetic of pure minimalism. Every opening is an invitation to step into light, space, and architectural poetry.
Security and peace of mind are never sacrificed for elegance. The innovative mullion lock engages automatically, while the bespoke multi-point locking system—available in an electrified version—ensures safety without compromise.
MOTION 61 FS is more than an architectural element; it is a statement of vision, craftsmanship, and contemporary luxury. It elevates every space it touches, delivering unmatched sophistication, timeless elegance, and limitless design freedom.
Technical characteristics
| Bottom track height | 55 mm |
| Floor step | 0 / 6 / 12 / 28 / 43 / 55 / 71 mm |
| Frame Height, Horizontal Top | 80 / 104 mm |
| Frame Height, Vertical | 64 mm |
| Frame Width | 74 mm |
| Tile Insert | 20 mm |
| Floor Typology | Step, Submerged |
| Riding Typology | Bottom Rolling |
| Sliding / Alignment rollers | Stainless Steel |
| Sash Height, Vertical | 27 mm |
| Sash Height, Horizontal | 27 mm |
| Sash Width | 60 mm |
| Centre Mullion Height | 68 mm |
| Max. Weight per Sash | 130 Kg |
| Max. Sash Width | 1300 mm |
| Max. Sash Height | 3000 mm |
| Opening type | Fold Slide |
| Glazing Width Possibilities | 32 / 45 mm |
| Maximum Locking Points | 5 |
| Sealing Type | 4 Gaskets |
Performances
| Fabrication Thermal Transmittance EN ISO 10077-2 | (Uw) ≥1.0 W/(m2K) |
FLOOR
TYPOLOGIES
MIDDLE
TYPOLOGIES
CONSTRUCTION
TYPOLOGIES
Submerged, Tile
Step with overlap
Step
Submerged, Pipe
Submerged, Pipe
Submerged, Pipe, Fin
Submerged, inline gutter, fin
Submerged, External gutter, fin
Submerged, Interior
Submerged with overlap
Max. Sash Width (W) 1300 mm Max. Sash Height (H) 3000 mm
Outward opening
LEFT - 2, 3, 4, 5, 6, 7, 8 Sashes
RIGHT - 0 Sashes
LEFT - 2, 3, 4, 5, 6, 7 Sashes
RIGHT - 1 Sash
LEFT - 2, 3, 4, 5, 6 Sashes
RIGHT - 2, 3, 4, 5, 6 Sashes
Corner Outward openning
LEFT - 2, 3, 4, 5, 6 Sashes
RIGHT - 2, 3, 4, 5, 6 Sashes
Inward opening
LEFT - 2, 3, 4, 5, 6, 7, 8 Sashes
RIGHT - 0 Sashes
LEFT - 2, 3, 4, 5, 6, 7 Sashes
RIGHT - 1 Sash
LEFT - 2, 3, 4, 5, 6 Sashes
RIGHT - 2, 3, 4, 5, 6 Sashes
LEFT - 2, 3, 4, 5, 6 Sashes
RIGHT - 2, 3, 4, 5, 6 Sashes
