MOTION 9700 MINIMAL CASEMENT HINGED DOOR SYSTEM
Motion 9700 is a minimal casement door system featuring a completely flat appearance with no visible rebate, delivering a clean and contemporary architectural expression. The sash dimensions have been reduced to just 36 mm, even for doors reaching heights of up to 5 meters, ensuring exceptionally slim proportions at large scales.
All doors are equipped with a custom-designed multi-point locking system, engineered to secure and seal the door continuously from bottom to top using a combination of wedges and mushroom cams. For enhanced convenience and access control, electric locking is available, enabling operation via remote control, keypad, or smartphone application.
A range of threshold designs is available, including solutions with a hidden drainage gutter to ensure superior water management while maintaining a minimal visual profile.
Motion 9700 accommodates glass thicknesses from 32 to 46 mm, making it suitable for triple-glazed configurations. The system is ideally suited for projects that demand high thermal and acoustic performance, combined with minimal dimensions and refined architectural detailing.
Technical characteristics
| Frame Profile Height | 26 mm |
| Frame Profile Width | 60 mm |
| Sash Profile Height | 27 / 36 mm |
| Sash Profile Width | 60 mm |
| Opening Type | Hinged |
| Max sash width | 1400 mm |
| Max sash height | 5000 mm |
| Max Sash weight | 300 Kg |
| Glazing width possibilities | 32 - 45 mm |
| Max Locking Points | 9 |
| Thermal Break width | 20 / 24 |
| Sealing Type | 3 Gaskets |
Performances
| Fabrication Thermal Transmittance EN ISO 10077-2 |
(Uw) ≥0.9 W/(m2K) |
